Coil-Service-Center.
Processing of strips and sheets.
We process customer requests in our processing center in Mannheim.
Here we can react quickly with a high and varied storage capacity and score points with customer-friendly service. With expertise and precise execution, our motivated processing team ensures that metals reach our customers in the desired requirements and quality >just-in-time<.
Our extensive machinery enables us to offer you a comprehensive package of services:
- Cross-cutting and slitting
- Intermediate storage
- Oiling
- Stamping
- Limited tolerances
- Wrapping
- Packaging
What we can do for you:
Sheets
Customizable and flexible according to your requirements.
Special formats / cuts
Fix lenghts sheets up to 12.000 mm
Fix - fix cuts, width and length cuts.
Slitted coils
Steel / stainless steel / aluminum straps
We cut customer-specific strips from steel, stainless steel and aluminum on the most modern cutting machines. The processing of refined material is also possible.
On request, we can cut your material fat-free or with a narrowed saber and width tolerances far below the DIN standard.
Processing of cross-cutting.
Our machinery includes two cut-to-length lines, one modern new acquired in 2022 and one completely overhauled in 2023.
Output of the machinery:
| Material strengths: | 0,50 - 4,0 m |
| Material widths: | 200 - 1.600 mm |
| Material lenght: | 300 - 10.000 mm |
| Coil: | max. 4,5 to. |
| Tolerances: | 1/2 EN |
| Stamping: | up/down |
| Foil: | up/down/double-sided |
| Paper: | yes |
Processing slitting.
In the slitting area, we expanded our existing machinery to currently four slitting lines in 2023 with a modern new acquisition.
Output of the machinery:
| Material strengths: | 0,50 - 4,0 m |
| Material widths: | 20 - 1.600 mm |
| RID: | 400/500 mm |
| RAD: | max. 1600 mm |
| Coil: | max. 4,5 to. |
| Tolerances: | 1/2 EN |
| Foil: | p/down/double-sided |
| paper sleeve: | yes |
| Paper insert: | yes |
Small / large coils
Processing of coils and sheets
Decoiling | Rewinding tapes onto other tape weights (small coils)
Subcontracting
We offer an all-round package consisting of incoming goods, intermediate storage, processing, packaging, transport, just-in-time.
Foliation
We coat metal sheets and plates on one and both sides on our foiling systems.
We use various standard or laser foils depending on the customer's requirements.
| Film type | Manufacturer | Label | Thickness | Application examples |
|---|---|---|---|---|
| PF 561 C / 80 (Orientation) |
Polifilm | Red arrows on grey-white surface UV-resistant 12 months | 80 μm | All mill-finished aluminium surfaces, anodized painted, coils, sheets |
| PF 84 C (Laserfoil) |
Polifilm | Laser marking in blue on black surface | 100 μm | For all surface qualities Use on CO2 and solid-state lasers |
| PF 22 | PF | Blue transparent | 50 μm | Bedingt UV-beständig, Alu, Edelstahl |
| A 15 | Coefilm | Limited UV resistance aluminium, stainless steel | 50 μm | UV resistance |
- UV resistance according to Western European climate = 300 h QUV test.
- When removing protection films, the processing temperature should be >10°C - <40°C!
- Other film types and other film manufacturers are available on request
